How to use a power bank to charge Spark?

DurhamPro

Active Member
Joined
Dec 20, 2017
Messages
30
Likes
3
Age
55
#1
I have a couple of high powered power banks that I would love to be able to use to charge my Spark in the field. I think I might have found a solution to the problem. It is a bit of a work around but looking for opinions.


EABB8E9B-9EF6-4661-8B00-419DD70D66E8.jpeg 0F27266F-1ACB-4068-9453-BE62E483FD7D.jpeg

Joined
Apr 15, 2018
Messages
9
Likes
4
Age
34
#2
This setup is not going to work. The USB to 12V Cigarette adapter you have listed can only output 12V 0.8A. This won't be enough to power the DJI Spark Car charger adapter. It doesn't show exactly the input it needs, but I would say it needs at least 5A to power.

Joined
Mar 2, 2018
Messages
18
Likes
3
Location
Ohio
#5
I don't understand how you're planning to use the USB to 12-volt adapter. What sort of power bank are you talking about? I've used a 20000 mah USB power bank and just plugged a USB cable from it into the Spark and it charged the battery.

I also just got one of those 3-in-1 chargers you show in your post and so far it's worked okay charging Spark batteries when it's plugged into the cigarette lighter plug (or whatever people call that 12-volt plug in cars these days, by cracky).

I'm going to be taking my Spark down to my off-grid cabin tomorrow and plan to use the 3-in-1 charger to recharge the Spark batteries using a marine battery I have hooked up to a solar panel there; never had a problem charging any other electronics item that way but I'll let you know if for some reason it doesn't work.

Joined
Apr 15, 2018
Messages
9
Likes
4
Age
34
#6
If you don't mind charging one battery at a time, you can actually plug the DJI Spark into the PowerBank with the micro-USB port next to the micro-SD card slot. It can take a 3A charge rate for about 1h20m charge time for one battery. With 2A it's around 1h40m.

Joined
Apr 15, 2018
Messages
9
Likes
4
Age
34
#7
I found you a product you can use. It will use your power bank to charge 1 DJI Spark battery. It's basically a USB 5V adapter to DJI Spark 13V.
DJI Spark USB Charger.PNG


DurhamPro

Active Member
Joined
Dec 20, 2017
Messages
30
Likes
3
Age
55
#8
I don't understand how you're planning to use the USB to 12-volt adapter. What sort of power bank are you talking about? I've used a 20000 mah USB power bank and just plugged a USB cable from it into the Spark and it charged the battery
.
I have a couple of 25000 usb power banks I was going to plug the usb to 12 volt in and then connect the 12 volt to spark adapter in to it. I might have to just charge batteries when the spark is on the ground.

I was hoping to charge more than one battery at a time from my powerbank while flying with others. That charge converter looks interesting and light weight but it doesn’t look like Amazon can get it to Canada in time before I fly in a week without costing an arm and a leg.

Joined
Mar 2, 2018
Messages
18
Likes
3
Location
Ohio
#10
I have a couple of 25000 usb power banks I was going to plug the usb to 12 volt in and then connect the 12 volt to spark adapter in to it.
OK, got it. I gotta agree with Genchau; not enough amps there.

I looked at the same item you show just above here, but decided for three dollars US more I'd give the 3-in-1 a chance. It definitely charges a battery faster than charging from the Spark's USB port. Dunno if that's good or bad, or how it compares to the official DJI multi-charger charge rate.

Joined
Mar 22, 2018
Messages
5
Likes
0
Age
53
#11
Being it was my birthday a couple of weeks back the Mrs bought me this from DJI site. Charge it up and it will Charge 3 batteries, 1 in the drone 1st then it will pick the next battery with the most charge, then the 3rd one. Also has USB output for either the controller or a moble/tablet. Can also be used with the DJI charger and be left on charge in doors. 1524472913785.jpg


Yowza

Well-Known Member
Joined
Jan 28, 2018
Messages
62
Likes
18
Age
59
#12
Being it was my birthday a couple of weeks back the Mrs bought me this from DJI site. Charge it up and it will Charge 3 batteries, 1 in the drone 1st then it will pick the next battery with the most charge, then the 3rd one. Also has USB output for either the controller or a moble/tablet. Can also be used with the DJI charger and be left on charge in doors. View attachment 4697
Got one works great, and also holds the spark and the batteries very securely

Likes: FZR750

Vilco

Well-Known Member
Joined
Dec 14, 2017
Messages
58
Likes
15
Age
46
#14
Never fails, I found the answer but the company won't ship to Canada WTF!
View attachment 4675
Beware, these only work with Quickcharge enabled powerbanks or similarly powerful: I had an old 20000 mAh powerbank and it has never recharged a batttery, then I got a Quickcharge 3.0 powerbank and it does recharge.

Joined
Nov 30, 2017
Messages
22
Likes
8
Age
64
#15
Just ordered one of these...from Amazon.


Parallel charges and larger battery capacity than the OEM DJI portable charger. A few buck less as well.

Will test and advise.


DurhamPro

Active Member
Joined
Dec 20, 2017
Messages
30
Likes
3
Age
55
#16
I saw that one and it looks great, the problem for me is the size and the weight but mostly the weight, It weighs almost 3lbs.

I just ordered this one. It has the weight advantage at just over a pound and with a 110 volt outlet is not limited to being used exclusively for the spark. I will let everyone know what I think of it when it arrives sometime later today. On the Dji Spark forum a gentleman bought this power supply and was able to recharge all 4 of his spark batteries per charge so this should do it for me.

Screen Shot 2018-04-28 at 10.58.35 AM.png


DurhamPro

Active Member
Joined
Dec 20, 2017
Messages
30
Likes
3
Age
55
#17
Charger arrived, looks great so far. I have it on charge and will try it out after I deplete the batteries on Sparky. As an added bonus, the case for the battery charger is a perfect fit for Sparky and a couple of batteries.
